How to Choose an Furniture Paint Spraying Machine

How to Choose an Furniture Paint Spraying Machine

CNC Paint Spraying Machine for Wooden Door

Affordable Furniture Paint Spraying Machine with the Advantage of Maintaining a High Degree of Flexibility

1.  3D Scaner, special reading software read the dimension and routed grooves on the panel

2.  Automatic self programming and Painting

3.  Automatic Spray guns and paint tube cleaning system

4.  Industrial PC and touch screen control, easy operation

5.  Output: 20-25 doors per hour

6.  Application: Raised or curved panels, Flat & Raised doors, Indoor& Outdoor furniture, Bedrooms, Stairs, Windows, Interior coverings, Suspended ceilings, Flat slabs for external wall covering, Pre-paintend sheet, Noise barriers , Metal sheets and panels, and plastic parts

GODN provides compact and affordable Furniture Paint Spraying Machine with the advantage of maintaining a high degree of flexibility.

Description of Furniture Paint Spraying Machine

The Automatic Furniture Paint Spraying Machine is specific designed to spray the various panel-type workpiece, like wooden panels, flat door, raised door, cabinet door, stair and other furniture components.

Features of Furniture Paint Spraying Machine

1. Furniture Paint Spraying Machine allows paint guns to operate in five axes (X,Y,Z,A,B);

2. Gun movements are programmable: linear motion goes along the X,Y,Z axis and rotation motion goes around the vertical (A) and horizontal (B) axis;

3. Painting head allows for installation of up to 4 automatic paint guns;

4. Number of installed paint spray guns and their functionality (e.g. rotary or fixed) depends on specifics of a painting process;

5. Painting head speed is up to 100 m/min in the horizontal plane (along the X and Y axes) and up to 30 m/min in the vertical plane (along the Z axis);

6. Automatic paint spray guns that apply material with preset working parameters minimize paint material losses, reduce time of painting process and filter fatigue;

7. A glazed spray booth with an air filtration system and inside lighting allows for ongoing control of a painting process;

8. Service door facilitates access to the interior of the paint machine which is incorporated in the system of emergency shutdown of the paint machine in the event of opening it during operation;

9. Compact design of the paint machine along with accessories and equipment minimizes amount of space required for installation of the machine and current operations;

10. The turntable increases efficiency of operations by shortening loading and unloading times of workpieces;

11. The upender allows the door leaf to be painted on both sides during a single loading of the painting machine;

12. Aperture stop automatically closes and opens when the operating mode is activated to ensure maximum cleanliness in the lacquering area.

13. Automatic paint reclaim system and spray gun cleaning system is applied;

14. It can be installed in existing paint booths with a pre-installed air exchange system.

Technical Parameters of Furniture Paint Spraying Machine

Max.Working Dimension 2500x1300x300mm
Max.Working Weight 50kg
Gun Movement Speed 100m/minute
Total Power 4.3kw
Compressed air pressure 0.6-0.8Mpa/6-8Bar
Compressed air consumption 100 l/min (excluding paint spray guns)
Working Efficiency 1.5-3minutes per working area
Loading time of elements into the working area 10s (turntable rotation time)
Operator 1-2 person
Weight 2800kg
Overall Dimension 5700*3600*2725mm



Footprint of Furniture Paint Spraying Machine

 footprint of the spray paint machine

Application Fields of Furniture Paint Spraying Machine

application of a spray paint machine

Are you considering investing in a Furniture Paint Spraying Machine? We look at all of the benefits you can reap when making the shift towards machine spray painting.

Benefits of Using a Furniture Paint Spraying Machine

If you work in a business that is within the industrial and manufacturing industries, including furniture, construction and automotive, the chances are you have needed to work with paint products for finishing your products.

Whilst working with paints can be a rewarding process, it can also be a difficult, time consuming, and labour intensive process, depending on what it is you are having to paint. There are however ways around this, by using a Furniture Paint Spraying Machine to automate the process.

Need some convincing on why you should invest in a Furniture Paint Spraying Machine and use it in your production process? Here are some of the benefits you can expect from a Furniture Paint Spraying Machine.

Speed and productivity

One of the main and most obvious benefits of using a Furniture Paint Spraying Machine is the speed in which they can complete your paint jobs. If your product line is filled with items that need to be painted a Furniture Paint Spraying Machine can get the work done faster and more consistently than manually spraying. Don`t worry, while Furniture Paint Spraying Machines work faster, they don`t compromise on quality they improve it!

Furniture Paint Spraying Machines will improve productivity throughout your factory, removing bottlenecks often created by the painting process, and de-skilling the operation to make labour recruitment less specialised.

Furniture Paint Spraying Machines are available in a variety of configurations that can be tailored to suit low, medium and high volume requirements, and Furniture Paint Spraying Machines are designed for maximum flexibility and ease of use. With Furniture Paint Spraying Machine options for single and double arm reciprocating machines with 4 to 8 spray gun capability, single or double 6 axis control spray heads and complete single or double robot spray systems the solutions are endless!

Consistent coating

A Furniture Paint Spraying Machine can consistently paint products with an even and controlled thickness of paint, ensuring total coverage with a smooth, professional and high quality finish. Of course, maintaining high quality finishes depends on regular cleaning of your Furniture Paint Spraying Machine!

With complete control of the spraying process a Furniture Paint Spraying Machine can provide significant savings on paint usage, typically around 20%, against manually sprayed products, which can go a long way to helping finance the Furniture Paint Spraying Machine of your choice!

Accessible & Easy to Use

Furniture Paint Spraying Machines whilst being smart and innovative machines are easy to use. Your workers can easily implement these into their working routine and use them daily with no complications due to the easy user-interface and fast set up. The Furniture Paint Spraying Machines are fully accessible for maintenance and cleaning, and filters are easily changed, so no excuses for a dirty machine!

Software - the software installed on our Furniture Paint Spraying Machines has been developed over many years of experience manufacturing and installing Furniture Paint Spraying Machines. The software is easy to use and allows the operator full control of the relevant machine functions and to save programmes created for different applications.

Spray Machine or Manual Spraying?

There are many benefits to a spray machine compared to manual spraying already mentioned but here is an important one

When manually spraying, overspray is a major issue due to the operator being human! When operators get tired the spray quality drops resulting in inconsistent finishes and excess paint usage.  However, Furniture Paint Spraying Machines have control of the paint quantity and overspray from the machine control, and have a specially designed system to ensure better air distribution, which helps to direct paint to the products being sprayed, resulting in uniform finishing and thickness providing significant savings on paint usage and high quality, consistent finishing, time and time again.

Invest in a Furniture Paint Spraying Machine Today

Are you ready to ramp up the productivity in your workplace and send more products out of the door of your factory? Then a Furniture Paint Spraying Machine is an essential piece of equipment to add to your current set-up.

Here at GODN Machines, we have years of experience in providing businesses with high-quality machinery and equipment. Get in touch with a member of our team if you have any questions about our comprehensive range of Furniture Paint Spraying Machine as well as any other questions or queries about our business or the other range of products we offer.

Our mission is to provide businesses with innovative machinery and tools to help them compete in this highly competitive world and this particularly competitive sector. GODN Machines Ltd are the perfect choice for Furniture Paint Spraying Machines. Get yours today.
